RFID Enclosures (Cabinets, Fridges, Freezers)
RFID enclosures are cabinet, freezer and refrigerator Jetstream devices. They not only support most Jetstream commands and events but extend them by enabling access control and the ability to remotely lockdown.To learn more about the specific Terso devices that match this device type, vist their product detail pages at tersosolutions.com.
Compact RFID Cabinet (TS032, TS035, TS037, TS050)
Large RFID Cabinet (TS030, TS056)
Compact RFID Refrigerator (TS029)
Compact International RFID Refrigerator (TS055, TS060, TS061)
Large RFID Refrigerator (TS074)
Compact RFID Freezer (TS031 TS034, TS036, TS038, TS042, TS043, TS047, TS048, TS052, TS054, TS068)
Large RFID Freezer (TS078)
The Countertop Cabinet and Security Cabinets are sufficiently distinct in function that they are treated as their own device types.
Name | Supported |
|---|---|
Yes | |
Yes | |
Yes | |
Yes | |
Yes | |
Yes | |
Yes | |
Yes | |
Yes |
Name | Description | Data Type | Min | Max | Default |
|---|---|---|---|---|---|
ACLockdownOnPowerFailure | Prevent end user access to the enclosure during a power failure event. | Bool | 0 | 1 | 1 |
ACLogEntryOnPowerFailure | Generate a LogEntryEvent when AC power is lost and returns. | Bool | 0 | 1 | 1 |
AggregateEventScanCount | Number of times the enclosure should scan after an end user closes the enclosure door. | Int | 1 | 100 | 2 |
AggregateEventScanDelay | Number of times the enclosure should wait between scans after an end user closes the enclosure door. | Int | 1 | 60 | 1 |
AggregateEventScanTime | The time of each individual scan in seconds after an end user closes the enclosure door. | Int | 0 | 300 | 10 |
Antenna1TxPower | The dB transmit power of antenna 1. | Int | 15 | 32 | 26 |
Antenna1RxSensitivity | The dB receive sensitivity of antenna 1. | Int | -80 | -30 | -65 |
Antenna2TxPower | The dB transmit power of antenna 2. | Int | 15 | 32 | 26 |
Antenna2RxSensitivity | The dB receive sensitivity of antenna 2. | Int | -80 | -30 | -65 |
Antenna3TxPower | The dB transmit power of antenna 3. | Int | 15 | 32 | 26 |
Antenna3RxSensitivity | The dB receive sensitivity of antenna 3. | Int | -80 | -30 | -65 |
Antenna4TxPower | The dB transmit power of antenna 4. | Int | 15 | 32 | 26 |
Antenna4RxSensitivity | The dB receive sensitivity of antenna 4. | Int | -80 | -30 | -65 |
AutoUpdate | Automatically update to the latest Firmware version as soon as it is released. | Bool | 0 | 1 | 0 |
BatteryThreshold | The battery voltage threshold to determine a good battery. | Float | 0 | 30 | 23.0 |
CommandPollInterval | The number of minutes between polling for device commands in Jetstream. | Int | 0 | 600 | 60 |
CommsReboot | Time in minutes to wait for communication to Jetstream to be restored before a reboot occurs. | Int | 10 | 1440 | 230 |
CommsReconnectInterval | Time in seconds to wait before attempting to communicate with Jetstream if there were any communication problems. | Int | 0 | 60 | 10 |
CommsTimeout | Time in seconds to wait for a reply from Jetstream after sending an event or command response. | Int | 0 | 60 | 10 |
DNS | The DNS to be used in a static LAN environment. When set to '0.0.0.0', the DHCP assigned DNS server is used instead. | IP Address | 0.0.0.0 | 255.255.255.255 | 0.0.0.0 |
DisplayBacklight | The brightness percentage for the LCD screen's backlight. | Int | 0 | 100 | 100 |
DisplayContrast | The contrast percentage for the LCD screen. | Int | 0 | 100 | 50 |
DoorOpenTimeLimit | Time in seconds the door can be left open before generating a LogEntryEvent. | Int | 1 | 3600 | 300 |
DoorUnlockTimeLimit | Time in seconds the door is unlocked after a user is granted access. | Int | 1 | 3600 | 5 |
Gateway | The gateway address to be used in a static LAN environment. When set to '0.0.0.0', the DHCP assigned Gateway address is used instead. | IP Address | 0.0.0.0 | 255.255.255.255 | 0.0.0.0 |
HeartbeatEventInterval | The number of minutes between sending a HeartbeatEvent. A setting of 0 will disable HeartbeatEvents. | Int | 0 | 600 | 60 |
InactivityInterval | Time in seconds communications will wait before re-establishing a connection if there is no activity. | Int | 0 | 3600 | 300 |
IP | The IP address to be used in a static LAN environment. When set to '0.0.0.0', the DHCP assigned IP address is used instead. | IP Address | 0.0.0.0 | 255.255.255.255 | 0.0.0.0 |
JetstreamDeviceUrl | The URL to which the enclosure sends Jetstream messages. | String | - | - | |
JetstreamWebsocketAppEndpoint | The Jetstream resource used to connect for WebSocket communications. Using '#' will disable WebSocket communications. | String | - | - | /dwsliveconnection.ashx |
LanguageFile | The language file to use to display messages on the enclosure's LCD screen. | String | - | - | lang/tsi-en-us.xml |
LocationService | Use location based services for the enclosure. The Geolocation of the enclosure will be sent in a SensorReadingEvent. | Bool | 0 | 1 | 0 |
LogEntryLevel | The verbosity of the logs sent by the enclosure
| String | Off | Debug | Error |
LogFileLevel | The verbosity of the logs saved locally on the enclosure
| String | Off | Debug | Off |
ObjectEventHour | The hour to perform the daily system scan as well as other system checks. A setting of -1 will disable ObjectEvents. | Int | -1 | 23 | 0 |
ObjectEventScanCount | The number of times to scan during a GetEPCListCommand or during the daily system scan. | Int | 1 | 100 | 2 |
ObjectEventScanDelay | Number of seconds the enclosure should wait between scans. | Int | 1 | 60 | 1 |
ObjectEventScanTime | The time in seconds for each scan during a GetEPCListCommand or during the daily system scan. | Int | 1 | 300 | 10 |
PingInterval | Time in seconds between client initiated pings when using WebSockets. A setting of 0 disables client pings. | Int | 0 | 3600 | 0 |
ReaderNumAntennas | The number of antennas the enclosure is using. | Int | 0 | 4 | 4 |
ReaderLockdownOnFailure | Prevent end user access to the enclosure if communications fail with the internal RFID reader. | Bool | 0 | 1 | 1 |
ReaderLogEntryOnFailure | Generate a LogEntryEvent when communications to the internal RFID reader fails. | Bool | 0 | 1 | 1 |
ScanMode | Specifies whether the reader should scan in Single, Dual, or Suppression modes. | String | - | - | Single |
SecureSocket | Use secure communications over HTTPS for the enclosure. | Bool | 0 | 1 | 1 |
SensorALockdownHighTemp | High temperature threshold in Celsius for probe A to lockdown the enclosure. | Int | -100 | 100 | 100 |
SensorALockdownLowTemp | Low temperature threshold in Celsius for probe A to lockdown the enclosure. | Int | -100 | 100 | -100 |
SensorALogEntryEventHighTemp | High temperature threshold in Celsius for probe A to send a LogEntryEvent. | Int | -100 | 100 | 100 |
SensorALogEntryEventLowTemp | Low temperature threshold in Celsius for probe A to send a LogEntryEvent. | Int | -100 | 100 | -100 |
SensorAOffset | The offset, in degrees Celsius, to apply to the temperature readings from temperature probe A. | Int | -100 | 100 | 0 |
SensorBLockdownHighTemp | High temperature threshold in Celsius for probe B to lockdown the enclosure. | Int | -100 | 100 | 100 |
SensorBLockdownLowTemp | Low temperature threshold in Celsius for probe B to lockdown the enclosure. | Int | -100 | 100 | -100 |
SensorBLogEntryEventHighTemp | High temperature threshold in Celsius for probe B to send a LogEntryEvent. | Int | -100 | 100 | 100 |
SensorBLogEntryEventLowTemp | Low temperature threshold in Celsius for probe B to send a LogEntryEvent. | Int | -100 | 100 | -100 |
SensorBOffset | The offset, in degrees Celsius, to apply to the temperature readings from temperature probe B. | Int | -100 | 100 | 0 |
SensorReadingEventInterval | The number of minutes between sending a SensorReadingEvent. A setting of 0 will disable SensorReadingEvents. | Int | 0 | 600 | 60 |
Subnet | The subnet address to be used in a static LAN environment. When set to '0.0.0.0', the DHCP assigned subnet is used instead. | IP Address | 0.0.0.0 | 255.255.255.255 | 0.0.0.0 |
The list below are some common, potential LogEntryEvents an enclosure may send in. However, not all possible LogEntryEvents are listed in this table. The LogEntryLevel in use determines which LogEntryEvents are sent to Jetstream.
Name | Description |
|---|---|
ACPowerFailure | ACPowerFailure occurs when the enclosure loses AC power and is running on battery backup. |
ACPowerRestore | ACPowerRestore occurs when the enclosure has AC power restored. |
CorruptFlash | CorruptFlash occurs when the enclosure believes there is a problem with the flash memory. |
DoorBreach | DoorBreach occurs when the door lock is released by something other than the enclosure. For example, someone prying the door open would cause this LogEntryEvent to be generated. |
DoorOpen | DoorOpen occurs when the door is left open for greater than the DoorOpenTimeLimit. |
DoorOpenRestore | DoorOpenRestore occurs when the enclosure's door is closed after a DoorOpen scenario. |
DoorSensorFailure | DoorSensorFailure occurs when the enclosure believes there is a problem with the door sensor. |
InvalidPass | InvalidPass occurs when an RFID pass is presented to the pass reader which does not match any value on the enclosure’s synced credentials list. |
LowBattery | LowBattery occurs when the enclosure's internal UPS battery voltage is less than the BatteryThreshold. |
LowFlashMemory | LowFlashMemory occurs when the enclosure has less than 25% flash memory. |
LowMemory | LowMemory occurs when the enclosure has less than 25% memory. This event will be sent every hour until the device reboots. Reboot occurs automatically if memory drops to 10%. |
NewFirmwareDownloadError | NewFirmwareDownloadError occurs when a request to upgrade firmware fails. |
ReadException | ReadException occurs when there is an issue performing an RFID scan. |
ScanInterruptionAlarm | ScanInterruptionAlarm occurs when someone interrupts a scan by opening the door. |
Shutdown | Shutdown occurs when the enclosure is powered down. |
Startup | Startup occurs whenever the enclosure is started up. |
Temperature | Temperature occurs when a temperature threshold set by SensorA/BLogEntryEventHighTemp or SensorA/BLogEntryEventLowTemp has been reached. |
TemperatureRestore | TemperatureRestore occurs when an enclosure has gone back into normal temperature range. |
UserPassReaderFailure | UserPassReaderFailure occurs when the enclosure loses its connection to the pass reader. |
UserPassReaderRestore | UserPassReaderRestore occurs when the enclosure has restored a connection to the pass reader. |
Enclosures typically have two temperature probes installed. A SensorReadingEvent is periodically generated reporting the temperature on the probe(s).
Name | Description |
|---|---|
TemperatureA | The temperature reported on probe A in Celsius. |
TemperatureB | The temperature reported on probe B in Celsius. |
